Gajaant Pipes combines virgin compound, controlled extrusion, in-house testing and third-party certification for dependable HDPE, MDPE and PVC pipe supply.
Showcase government approvals, BIS certifications, quality standards and laboratory compliance credentials required for public infrastructure projects.
Officially listed in Maharashtra Jeevan Pradhikaran list for public water networks.
Bureau of Indian Standards stamps present across every single extruded meter.
System level compliance validation for raw compound intake and production tolerance.
Independent lot testing logs confirming melt index, hydraulic pressure, and carbon density.
Fully equipped in-house testing lab executing hourly batch checks alongside 17+ years of manufacturing experience.
Dimensional parameters for PE-100 high-pressure piping per IS 4984 standards.
| OD (MM) | PN 2.5 | PN 4 | PN 6 | PN 10 | PN 16 | PN 20 |
|---|---|---|---|---|---|---|
| 20 mm | 1.2 | 2.0 | 2.3 | 2.8 | 4.0 | 2.3 |
| 25 mm | 1.5 | 2.0 | 2.3 | 3.5 | 5.0 | 3.0 |
| 32 mm | 2.0 | 2.0 | 2.4 | 4.4 | 6.4 | 3.6 |
| 40 mm | 2.0 | 2.3 | 3.0 | 5.5 | 8.0 | 4.5 |
| 50 mm | 2.9 | 2.9 | 3.7 | 6.9 | 10.0 | 5.6 |
| 63 mm | 2.0 | 3.6 | 4.7 | 8.6 | 12.6 | 7.1 |
| 75 mm | 2.3 | 4.3 | 5.6 | 10.3 | 15.0 | 8.4 |
| 90 mm | 2.8 | 5.2 | 6.7 | 12.3 | 18.0 | 10.1 |
| 110 mm | 3.4 | 6.3 | 8.2 | 15.1 | 22.0 | 12.3 |
| 160 mm | 5.0 | 9.2 | 11.9 | 21.9 | 31.9 | 17.9 |
All dimensions are in millimeters (mm).
Our dual-extrusion lines, precision quality control testing labs, and structured logistics network guarantee structural reliability at every stage.
Virgin PE-100 / PVC compound from indexed Indian producers, lot-tested on intake.
Twin-line extrusion with online wall-thickness gauging and vacuum sizing.
Hydro pressure, melt-flow index, density and carbon-black per IS norms.
Stenciled, bundled and shipped — full traceability by batch code.
Heavy. Patient. Reliable. Pipes that hold pressure through Marathwada summers and Konkan monsoons — and arrive at site exactly when your dealer promised.
Every batch is tested in-house and certified under IS 4984, IS 4985 and IS 14333.
Twin extrusion lines and a polished die-shop give us tight wall-thickness and consistency.
Virgin PE-100 and PVC compound — never re-processed scrap. CIPET-validated lots.
Dedicated dealer fleet across Maharashtra. Standard sizes ship within 48 hours.
Approved and certified by Maharashtra Jeevan Pradhikaran for reliable water supply projects.
